Gemini Mixing Station

Need to mix two part chemistries? Need to mix ViveSecure in the simplest way possible? The Gemini™ Model 150 Mixing Station is a unique, 7 GPM @ 40 PSI high-volume chemical proportioner that will simultaneously dilute and blend two chemical concentrates into one accurately diluted solution and quickly dispense it into larger containers and equipment. The unique Gemini™ “double venturi” injection system incorporates two completely separated venturis in one injector body and uses city water pressure (35 – 125 PSI) to draw and blend 2 chemical concentrates into the water stream independently so that the chemicals never mix until they are diluted. Dilution ratios are controlled independently with precision metering tips. Ball valve activation allows for hands-free dispensing.

  • Eliminates manual mixing and optimizes chemical utilization, employee safety and labor efficiency
  • Ball valve activation allows for hands-free dispensing
  • The unique Gemini™ proportioner draws 2 chemical concentrates and blends them downstream after dilution
  • Dilution ratios are controlled independently for each chemical using precision metering tips
  • One chemical suction tube is larger and capable of drawing more viscous chemicals
  • Water flow rate of 7 GPM @ 40 PSI
  • Chemical resistant wetted components ensure years of outstanding performance with minimal maintenance

Want to read more? You can learn more by reaching out using the form below, or by finding the Gemini Mixing Station Cut Sheet at the bottom of the page under “Additional Downloads”.
